Corvette Engine

1966 Corvette and 1967 Corvette

The 1966 Corvette, though similar in appearance to the previous year, received some small changes. The trim was done differently, including for the hood script. Also, a new square mesh cast grill was added, and the roof vents were removed. Headrests were available for the first time. However, the biggest change came with the introduction of the solid lift 427ci big block, which started out with a rating of 450hp but was reduced to 425hp shortly after introduction. Reasons why this was done are unknown.

In 1967 the Corvette L-88 made its debut at Le Mans. It's also the last of what is known as the Corvette mid-years (1963 to 1967). Due to the removal of the trim, the 1967 Corvette was the least adored of these model years.


1966 Specs:

  • Wheelbase: 98"
  • Track: 56.8" Front/57.6" Rear
  • Height: 49.8" Coupe
  • Length: 175.1"
  • Width: 69.6"
  • Curb Weight: 3,140 lbs.
  • Tire Size: 7.75" x 15"
  • Plant: St. Louis, MO

1966 Options:

Code Description Quantity
 19437  Base Corvette Sport Coupe   9,958
 19467  Base Corvette Convertible  17,762
 -  Genuine Leather Seats  2,002
 A01  Soft Ray Tinted Glass, All Windows  11,589
 A02  Soft Ray Tinted Glass, Windshield  9,270
 A31  Power Windows  4,562
 A82  Headrests  1,033
 A85  Shoulder Belts  37
 C07  Auxiliary Hardtop (Convertible)  8,463
 C48  Heater/Defroster Delete  54
 C60  Air Conditioning  3,520
 F41  Special Front and Rear Suspension  2,705
 G81  Positraction Rear Axle  24,056
 J50  Power Brakes  5,464
 J56  Special Heavy-Duty Brakes  382
 K66  Transistor Ignition System  7,146
 L36  427ci 390hp Engine  8,358
 L72  427ci 450/425hp Engine  5,116
 L78  396ci 425hp Engine  5,258
 L79  327ci 350hp Engine  7,591
 M20  4-Speed Manual Transmission  10,837
 M21  4-Speed Manual Close Ratio  13,903
 M22  4-Speed Manual Close Ratio, Heavy Duty  15
 M35  Powerglide Automatic Transmission  2,401
 N03  36-Gallon Fuel Tank, Coupe Only  66
 N11  Off-Road Exhaust System  2,795
 N14  Side Mount Exhaust System  3,617
 N32  Teakwood Steering Wheel  3,941
 N36  Telescopic Steering Column  3,670
 N40  Power Steering  5,611
 P48  Cast Aluminum Knock-Off Wheels  1,194
 P92  Whitewall Tires, 7.75" x 15" Rayon Cord  17,969
 T01  Goldwall Tires, 7.75" x 15" Nylon Cord   5,557
 U69  AM/FM Radio  26,383
 V74  Traffic Hazard Switch  5,764

Serial Numbers: 194376S100001 through 194376S127720

For convertibles, the fourth digit is a "6."

Suffix:

  • HD: 327ci 350hp, Manual Transmission and Air Injection Reactor
  • IK: 427ci 425hp, Manual Transmission
  • HE: 327ci 300hp, Manual Transmission
  • IL: 427ci 390hp, Manual Transmission
  • HH: 327ci 300hp, Manual Transmission and Air Injection Reactor
  • IM: 427ci 390hp, Manual Transmission and Air Injection Reactor
  • HO: 327ci 300hp, Automatic Transmission
  • IP: 427ci 450/425hp, Manual Transmission
  • HP: 327ci 300hp, Manual Transmission and Power Steering
  • IQ: 427ci 390hp, Automatic Transmission
  • HR: 327ci 300hp, Automatic Transmission and Air Injection Reactor
  • IR: 427ci 390hp, Automatic Transmission and Air Injection Reactor
  • HT: 327ci 350hp, Manual Transmission
  • KH: 327ci 350hp, Manual Transmission, Air Injection Reactor, Air Conditioning, and Power Steering

Colors:

RPO Exterior Quality Soft-Top Wheels Interior
 900  Tuxedo Black 1,190  Black/White/Beige  Black Black/Bright Blue/White and Blue/Red/Saddle/Silver/Green/Blue
 972 Ermine White 2,120  Black/White/Beige  Black Black/Bright Blue/White and Blue/Red/Saddle/Silver/Green/Blue
 974 Rally Red 3,366  Black/White/Beige  Black Black/Red
 976  Nassau Blue 6,100  Black/White/Beige  Black Black/Bright Blue/White and Blue/Blue
 978 Laguna Blue 2,054  Black/White/Beige  Black Black/Bright Blue/Blue
 980 Trophy Blue 1,463  Black/White/Beige  Black Black/Bright Blue/Blue
 982 Mosport Green 2,311  Black/White/Beige  Black Back/Green
 984 Sunfire Yellow 2,339  Black/White/Beige  Black Black
 986 Silver Pearl 2,967  Black/White/Beige  Black Black/Silver
 988 Milano Maroon 3,799  Black/White/Beige  Black Black/Saddle

1 967 Specs:

  • Wheelbase: 98"
  • Track: 56.8" Front/57.6" Rear
  • Height: 49.8" Coupe
  • Length: 175.1"
  • Width: 69.6"
  • Curb Weight: 3,155 lbs.
  • Tire Size: 7.75" x 15"
  • Plant: St. Louis, MO

1967 Options:

Code Description Quantity
 19437  Base Corvette Sport Coupe 8,504
 19467  Base Corvette Convertible  14,436
 -  Genuine Leather Seats 1,601
 A01  Soft Ray Tinted Glass, All Windows 11,331
A02 Soft Ray Tinted Glass, Windshield 6,558
 A31  Power Windows  4,036
 A82  Headrests  1,762
A85  Shoulder Belts 1,426
C07  Auxiliary Hardtop (Convertible) 6,880
C08  Vinyl Covering for Auxiliary Hardtop 1,966
C48  Heater/Defroster Delete 35
C60  Air Conditioning 3,788
F41  Special Front and Rear Suspension 2,198
G81  Positraction Rear Axle 20,308
J50  Power Brakes 4,766
J56  Special Heavy-Duty Brakes 267
K19  Air Injection Reactor 2,573
K66  Transistor Ignition System 5,759
L36  427ci 390hp Engine 3,832
L68  427ci 400hp Engine 2,101
L71  427ci 435hp Engine 3,754
L79  327ci 350hp Engine 6,375
L88  427ci 430hp Engine 20
L89  Aluminum Cylinder Heads for L71 16
M20  4-Speed Manual Transmission 9,157
M21  4-Speed Manual Close Ratio 11,015
M22  4-Speed Manual Close Ratio, Heavy Duty 20
M35  Powerglide Automatic Transmission 2,324
N03  36-Gallon Fuel Tank, Coupe Only 2
N11  Off-Road Exhaust System 2,326
N14  Side Mount Exhaust System 4,209
N36  Telescopic Steering Column 2,415
N40  Power Steering 5,747
N89  Cast Aluminum Bolt-0n Wheels 720
P92  Whitewall Tires, 7.75" x 15" 13,445
QB1  Redline Tires, 7.75" x 15" 4,230
U15  Speed Warning Indicator 2,108
U69  AM/FM Radio 22,193


Serial Numbers:
94377S100001 through 194377S122940

For convertibles, the fourth digit is a "6."

Base Engine: 350ci V8 300hp

Suffix:

  • HD: 327ci 350hp, Manual Transmission and Air Injection Reactor
  • IT: 427ci 430hp (L88), Manual Transmission
  • HE: 327ci 300hp, Manual Transmission
  • IU: 427ci 435hp, Manual Transmission and Aluminum Head
  • HH: 327ci 300hp, Manual Transmission and Air Injection Reactor
  • JA: 427ci 435hp, Manual Transmission and Air Injection Reactor
  • HO: 327ci 300hp, Automatic Transmission
  • JC: 427ci 400hp, Manual Transmission
  • HP: 327ci 300hp, Manual Transmission, Power Steering, and Air Conditioning
  • JD: 427ci 400hp, Automatic Transmission
  • HR: 327ci 300hp, Automatic Transmission and Air Injection Reactor
  • JE: 427ci 435hp, Manual Transmission
  • HT: 327ci 350hp, Manual Transmission
  • JF: 427ci 400hp, Manual Transmission and Air Injection Reactor
  • IL: 427ci 390hp, Manual Transmission
  • JG: 427ci 400hp, Automatic Transmission and Air Injection ReactorI
  • M: 427ci 390hp, Manual Transmission and Air Injection Reactor
  • JH: 427ci 435hp, Manual Transmission, Air Injection Reactor, and Aluminum Head
  • IQ: 427ci 390hp, Automatic Transmission
  • KH: 327ci 350hp, Manual Transmission, Air Injection Reactor, Air Conditioning, and Power Steering
  • IR: 427ci 390hp, Automatic Transmission and Air Injection Reactor

Colors:

RPO Exterior Quality Soft-Top Wheels Interior
 900  Tuxedo Black  815  Black/White/Turquoise  Silver Black/Red/Bright Blue/Saddle/White/Green/Turquoise
 972  Ermine White  1,423  Black/White/Turquoise  Silver Black/Red/Bright Blue/Saddle/White/Green/Turquoise
 974  Rally Red  2,341  Black/White/Turquoise  Silver Black/Red/White
 976  Marina Blue  3,840  Black/White/Turquoise  Silver Black/Bright Blue/White
 977  Lynndale Blue  1,381  Black/White/Turquoise  Silver Black/Turquoise/White
 980  Elkhart Blue  1,096  Black/White/Turquoise  Silver Black/Turquoise
 983  Goodwood Green  4,293  Black/White/Turquoise  Silver Black/Saddle/W/Green
 984  Sunfire Yellow  2,325  Black/White/Turquoise  Silver Black/White
 986  Silver Pearl  1,952  Black/White/Turquoise  Silver Black/Turquoise
 988  Marlboro Maroon  3,464  Black/White/Turquoise  Silver Black/Saddle/White
